What’s the maximum size of a node in JCR/AEM?

An interesting question which comes up every now and then is: “Is there a limit how large a JCR node can get?”.  And as always in IT, the answer is not that simple.

In this post I will answer that question and also outline why this limit is hardly a constraint in AEM development. Also I will show ways how you can design your application so that this limit is not a problem at all.

Continue reading “What’s the maximum size of a node in JCR/AEM?”

Sling Scheduled Jobs vs Sling Scheduler

Apache Sling and AEM provide 2 different approaches to start processes at a given time or in a given interval. It is not always trivial to make the right decision between these two, and I have seen a few cases of misuse already. Let’s dive into this topic and I will outline in what situation to use the Scheduler and when to use Scheduled Jobs.

Continue reading “Sling Scheduled Jobs vs Sling Scheduler”

How to analyze “Authentication support missing”

Errors and problems in running software manifest often in very interesting and non-obvious cases. A problem in location A manifests itself only with an unrelated error message in a different location B.

We also have one example of such a situation in AEM, and that’s the famous “Authentication support missing” error message.  I see often the question “I got this error message; what should I do now?”, and so I decided: It’s time to write a blog post about it. Here you are.

“Authentication support missing” is actually not even correct: There is no authentication module available, so you cannot authenticate. But in 99,99% of the cases this is just a symptom. Because the default AEM authentication depends on a running SlingRepository service. And a running Sling repository has a number of dependencies itself.

I want to highlight 2 of these dependencies, because they tend to cause problems most often: The Oak repository and the RepositoryInitializer service. Both must be up and be started/run succesfully until the SlingRepository service is being registered succesfully. Let’s look into each of these dependencies.

The Oak repository

The Oak repository is a quite complex system in itself, and there are many reasons why it did not start. To name a few:

  • Consistency problems with the repository files on disk (for whatever reasons), permission problems on the filesystem, full disks, …
  • Connectivity issues towards the storage (especially if you use a database or mongodb as storage)
  • Messed up configuration

If you have an “authentication support missing” message, you first check should be on the Oak repository, typically reachable in the AEM error.log. If you have an ERROR messages logged by any “org.apache.jackrabbit.oak” class during the startup, this is most likely the culprit. Investigate from there.

Sling Repository Initializer (a.k.a. “repoinit”)

Repoinit is designed to ensure that a certain structure in the repository is provided, even before any consumer is accessing it. All of the available scripts must be executed, and any failure will immediate terminate the startup of the SlingRepositoryService. Check also my latest blog post on Sling Repository Initializer for details how to prevent such problems.

Repoinit failures are typically quite prominent in the AEM error.log, just search for an ERROR message starting with this:

*ERROR* [Apache SlingRepositoryStartup Thread #1] com.adobe.granite.repository.impl.SlingRepositoryManager Exception in a SlingRepositoryInitializer, SlingRepositoryservice registration aborted …

These are 2 biggest contributors to this “Authentication support missing” error messages. Of course there are more reasons why it could appear. But to be honest, I only have seen these 2 cases in the last years.

I hope that this article helps you to investigate such situations more swiftly.

How to deal with RepoInit failures in Cloud Service

Some years, even before AEM as a Cloud Services, the RepoInit language has been implemented as part of Sling (and AEM) to create repository structures directly on the startup of the JCR Repository. With it your application can rely that some well-defined structures are always available.

In this blog post I want to walk you through a way how you can test repoinit statements locally and avoid pipeline failures because of it.

Repoinit statements are deployed as part of OSGI configurations; and that means that during the development phase you can work in an almost interactive way with it. Also exceptions are not a problem; you can fix the statement and retry.

The situation is much different when you already have repoinit statements deployed and you startup your AEM (to be exact: the Sling Repository service) again. Because in this case all repoinit statements are executed as part of the startup of the repository. And any exception in the execution of repoinits will stop the startup of the repository service and render your AEM unusable. In the case of CloudManager and AEM as a Cloud Service this will break your deployment.

Let me walk you through 2 examples of such an exception and how you can deal with it.

*ERROR* [Apache SlingRepositoryStartup Thread #1] com.adobe.granite.repository.impl.SlingRepositoryManager Exception in a SlingRepositoryInitializer, SlingRepositoryservice registration aborted java.lang.RuntimeException: Session.save failed: javax.jcr.nodetype.ConstraintViolationException: OakConstraint0025: /conf/site/configuration/favicon.ico[[nt:file]]: Mandatory child node jcr:content not found in a new node
at org.apache.sling.jcr.repoinit.impl.AclVisitor.visitCreatePath(AclVisitor.java:167) [org.apache.sling.jcr.repoinit:1.1.36]
at org.apache.sling.repoinit.parser.operations.CreatePath.accept(CreatePath.java:71)

In this case the exception is quite detailed what actually went wrong. It failed when saving, and it says that /conf/site/configuration/favicon (of type nt:file) was affected. The problem is that a mandatory child node “jcr:content” is missing.

Why is it a problem? Because every node of nodetype “nt:file” requires a “jcr:content” child node which actually holds the binary.

This is a case which you can detect very easily also on a local environment.

Which leads to the first recommendation:

When you develop in your local environment, you should apply all repoinit statements to a fresh environment, in which there are no manual changes. Because otherwise your repoinit statements rely on the presence of some things which are not provided by the repoinit scripts.

Having a mix of manual changes and repoinit on a local development environment and then moving it untested over is often leads to failures in the CloudManager pipelines.

The second example is a very prominent one, and I see it very often:

[Apache SlingRepositoryStartup Thread #1] com.adobe.granite.repository.impl.SlingRepositoryManager Exception in a SlingRepositoryInitializer, SlingRepositoryservice registration aborted java.lang.RuntimeException: Failed to set ACL (java.lang.UnsupportedOperationException: This builder is read-only.) AclLine DENY {paths=[/libs/cq/core/content/tools], privileges=[jcr:read]}
at org.apache.sling.jcr.repoinit.impl.AclVisitor.setAcl(AclVisitor.java:85)

It’s the well-known “This builder is read-only” version. To understand the problem and its resolution, I need to explain a bit the way the build process assembles AEM images in the CloudManager pipeline.

In AEM as a cloud service you have an immutable part of the repository, which consists out of the trees “/libs” and “/apps”. They are immutable, because they cannot be modified on runtime, not even with admin permissions.

During build time this immutable part of the image is built. This process merges both product side parts (/libs) and custom application parts (/apps) together. After that also all repoinit scripts run, both the ones provided by the product as well as any custom one. And of course during that part of the build these parts are writable, thus writing into /apps using repoinit is not a problem.

So why do you actually get this exception, when /libs and /apps are writeable? This is because repoinit is executed a second time. During the “final” startup, when /apps and /libs are immutable.

Repoinit is designed around that idea, that all activities are idempotent. This means that if you want to create an ACL on /apps/myapp/foo/bar the repoinit statement is a no-op if that specific ACL already exists. A second run of repoinit will do nothing, but find everything still in place.

But if in the second run the system executes this action again, it’s not an no-op anymore. This means that this ACL is not there as expected. Or whatever the goal of that repoinit statement was.

And there is only one reason why this happen. There was some other action between these 2 executions of repoinit which changed the repository. The only thing which also modifies the repository are installations of content packages.

Let’s illustrate this problem with an example. Imagine you have this repoinit script:

create path /apps/myapp/foo/bar
set acl on /apps/myapp/foo/bar
  allow jcr:read for mygroup
end

And you have a content package which comes with content for /apps/myapp and the filter is set to “overwrite”, but not containing this ACL.

In this case the operations leading to this error are these:

  • Repoinit sets the ACL on /apps/myapp/foo/bar
  • the deployment overwrites /apps/myapp with the content package, so the ACL is wiped
  • AEM starts up
  • Repoinit wants to set the ACL on /apps/myapp/foo/bar, which is now immutable. It fails and breaks your deployment.

The solution to this problem is simple: You need to adjust the repoinit statements and the package definitions (especially the filter definitions) in a way, that the package installation does not wipe and/or overwrite any structure created by repoinit. And with “structure” I do not refer only to nodes, but also nodetypes, properties etc. All must be identical, and in the best case they don’t interfere.

It is hard to validate this locally, as you don’t have an immutable /apps and /libs, but there is a test approach which comes very close to it:

  • Run all your repoinit statements in your local test environment
  • Install all your content packages
  • Enable write tracing (see my blog post)
  • Re-run all your repo-init statements.
  • Disable write tracing again

During the second run of the repoinit statements you should not see any write in the trace log. If you have any write operation, it’s a sign that your packages overwrite structures created by repoinit. You should fix these asap, because they will later break your CloudManager pipeline.

With this information at hand you should be able to troubleshoot any repoinit problems already on your local test environment, avoiding pipeline failures because of it.

The deprecation of Sling Resource Events

Sling events are used for many aspects of the system, and initially JCR changes were sent with it. But the OSGI eventing (which the Sling events are built on-top) are not designed for a huge volumes of events (thousands per second); and that is a situation which can happen with AEM; and one of the most compelling reasons to get away from this approach is that all these event handlers (both resource change event and all others) share a single thread-pool.

For that reason the ResourceChangeListeners have been introduced. Here each listener provides detailed information which change it is interested in (restrict by path and type of the change) therefor Sling is able to optimise the listeners on the JCR level; it does not listen for changes when no-one is interested in. This can reduce the load on the system and improve the performance.
For this reason the usage of OSGI Resource Event listeners are deprecated (although they are still working as expected).

How can I find all the ResourceChangeEventListeners in my codebase?

That’s easy, because on startup for each of these ResourceChangeEventListeners you will find a WARN message in the logs like this:

Found OSGi Event Handler for deprecated resource bridge: com.acme.myservice

This will help you to identify all these listeners.

How do I rewrite them to ResourceChangeListeners?

In the majority of cases this should be straight-forward. Make your service implement the ResourceChangeListeners interface and provide these additional OSGI properties:

@Component(
service = ResourceChangeListener.class,
configurationPolicy = ConfigurationPolicy.IGNORE,
property = {
ResourceChangeListener.PATHS + "=/content/dam/asset-imports",
ResourceChangeListener.CHANGES + "=ADDED",
ResourceChangeListener.CHANGES + "=CHANGED",
ResourceChangeListener.CHANGES + "=REMOVED"
})

With this switch you allow resource events to be processed separately in an optimised way; they do not block anymore other OSGI events.

How to handle errors in Sling Servlet requests

Error handling is a topic which developers rarely pay too much attention to. It is done when the API forces them to handle an exception. And the most common pattern I see is the “log and throw” pattern, which means that the exception is logged and then re-thrown.

When you develop in the context of HTTP requests, error handling can get tricky. Because you need to signal the consumer of the response, that an error happened and the request was not successful. Frameworks are designed in a way that they handle any exception internally and set the correct error code if necessary. And Sling is not different from that, if your code throws an exception (for example the postConstruct of a Sling Model), the Sling framework catches it and sets the correct status code 500 (Internal Server Error).

I’ve seen code, which catches exception itself and sets the status code for the response itself. But this is not the right approach, because every exception handled this way the developers implicitly states: “These are my exceptions and I know best how to handle them”; almost as if the developer takes ownership of these exceptions and their root causes, and that there’s nothing which can handle this situation better.

This approach to handle exceptions on its own is not best practice, and I see 2 problems with it:

  • Setting the status code alone is not enough, but the remaining parts of the request processing need to stopped as well. Otherwise the processing continues as nothing happened, which is normally not useful or even allowed. It’s hard to ensure this when the exception is caught.
  • Owning the exception handling removes the responsibility from others. In AEM as a Cloud Service Adobe monitors response codes and the exceptions causing it. And if there’s only a status code 500 but no exception reaching the SlingMainServlet, then it’s likely that this is ignored, because the developer claimed ownership of the exception (handling).

If you write a Sling Servlet or code operating in the context of a request it is best practice not to catch exceptions, but to let them bubble up to the Sling Main Servlet, which is able to handle it appropriately. handle exceptions by yourself, only if you have a better way to deal with them as to log them.

How to deal with the “TooManyCallsException”

I randomly see the question “We get the TooManyCallsException while rendering pages, and we need to increase the threshold for the number of inclusions to 5000. Is this a problem? What can we do so we don’t run into this issue at all?”

Before I answer this question, I want to explain the background of this setting, why it was introduced and when such a “Call” is made.

Sling rendering is based on Servlets; and while a single servlet can handle the rendering of the complete response body, that is not that common in AEM. AEM pages normally consistent of a variety of different components, which internally can consist of distinct subcomponents as well. This depends on the design approach the development has choosen.
(It should be mentioned that all JSPs and all HTL scripts are compiled into regular Java servlets.)

That means that the rendering process can be considered as tree of servlets, and servlets calling other servlets (with the DefaultGetServlet being the root of such a tree when rendering pages). This tree is structured along the resource tree of the page, but it can include servlets which are rendering content from different areas of the repository; for example when dealing with content fragments or including images, which require their metadata to be respected.

It is possible to turn this tree into a cyclic graph; and that means that the process of traversing this tree of servlets will turn into a recursion. In that case request processing will never terminate, the Jetty thread pool will quickly fill up to its limit, and the system will get unavailable. To avoid this situation only a limited number of servlet-calls per request is allowed. And that’s this magic number of 1000 allowed calls (which is configured in the Sling Main Servlet).

Knowing this let me try to answer the question “Is it safe to increase this value of 1000 to 5000?“. Yes, it is safe. In case your page rendering process goes recursive it terminates later, which will increase a bit the risk of your AEM instance getting unavailable.


Are there any drawbacks? Why is the default 1000 and not 5000 (or 10000 or any higher value)?” From experience 1000 is sufficient for the majority of applications. It might be too low for applications where the components are designed very granular which in turn require a lot of servlet calls to properly render a page.
And every servlet call comes with a small overhead (mostly for running the component-level filters); and even if this overhead is just 100 microseconds, 1000 invocations are 100 ms just for the invocation overhead. That means you should find a good balance between a clean application modularization and the runtime performance overhead of it.

Which leads to the next question: “What are the problematic calls we should think of?“. Good one.
From a high-level view of AEM page renderings, you cannot avoid the servlet-calls which render the components. That means that you as an AEM application developer cannot influence the overall page rendering process, but you can only try to optimise the rendering of individual (custom) components.
To optimise these, you should be aware, that the following things trigger the invocation of a servlet during page rendering:

  • the <cq:include>, <sling:include> and <sling:forward> JSP tags
  • the data-sly-include statement of HTL
  • and every method which invokes directly or indirectly the service() method of a servlet.

A good way to check this for some pages is the “Recent requests” functionality of the OSGI Webconsole.

The web, an eventually consistent system

For many large websites, CDNs are the foundation for delivering content quickly to their customers around the world. The ability of CDNs to cache responses close to consumers also allows these sites to operate on a small hardware footprint. However, compared to what they would have to invest if they operated without a CDN and delivered all content through their own systems, this comes at a cost: your CDN may now deliver content that is out of sync with your origin because you changed the content on your own system. This change is not done in an atomic fashion. This is the same “atomic” as in the ACID principle of database implementations.
This is a conscious decision, and it is caused primarily by the CAP theorem. It states that in a distributed data storage system, you can only achieve 2 of these 3 guarantees:

  • Consistency
  • Availability
  • Partition tolerance

And in the case of a CDN (which is a highly distributed data storage system), its developers usually opt for availability and partition tolerance over consistency. That is, they accept delivering content that is out of date because the originating system has already updated it.

To mitigate this situation the HTTP protocol has features built-in which help to mitigate the problem at least partially. Check out the latest RFC draft on it, it is a really good read. The main feature is called “TTL” (time-to-live) and means that the CDN delivers a version of the content only for a configured time. Afterwards the CDN fetches a new version will from the origin system. The technical term for this is “eventual consistent” because at that point the state of the system with respect to that content is consistent again.

This is the approach all CDNs support, and it works very reliable. But only if you accept that you change content on the origin system and that it will reach your consumers with this delay. The delay is usually set to a period of time that is empirically determined by the website operators, trying to balance the need to deliver fresh content (which requires a very low or no TTL) with the number of requests that the CDN can answer instead of the origin system (in this case, the TTL should be as high as possible). Usually it is in the range of a few minutes.

(Even if you don’t use a CDN for your origin systems, you need these caching instructions, otherwise browsers will make assumptions and cache the requested files on their own. Browsing the web without caching is slow, even on very fast connections. Not to mention what happens when using a mobile device over a slow 3G line … Eventual consistency is an issue you can’t avoid when working on the web.)

Caching is an issue you will always have to deal with when creating web presences. Try to cache as much as possible without neglecting the need to refresh or update content at a random time.

You need to constantly address eventual consistency. Atomic changes (that means changes are immediately available to all consumers) are possible, but they come at a price. You can’t use CDNs for this content; you must deliver it all directly from your origin system. In this case, you need to design your origin system so that it can function without eventual consistency at all (and that’s built in into many systems). Not to mention the additional load it will have to handle.

And for this reason I would always recommend not relying on atomic updates or consistency across your web presence. Always factor in eventual consistency in the delivery of your content. And in most cases even business requirements where “immediate updates” are required can be solved with a TTL of 1 minute. Still not “immediate”, but good enough in 99% of all cases. For the remaining 1% where consistency is mandatory (e.g. real-time stock trading) you need to find a different solution. And I am not sure if the web is always the right technology then.

And as an afterthought regarding TTL: Of course many CDNs offer you the chance to actively invalidate the content, but it often comes with a price. In many cases you can invalidate only single files. Often it is not an immediate action, but takes seconds up to many minutes. And the price is always that you have to have the capacity to handle the load when the CDN needs to refetch a larger chunk of content from your origin system.

Understanding AEM request processing using the OSGI “Recent Request” console

During some recent work on performance improvements in request processing I used a tool, which is part of AEM for a very long time now; I cannot recall a time when it was NOT there. It’s very simple, but nevertheless powerful and it can help you to understand the processing of requests in AEM much better.

I am talking about the “Recent Requests Console” in the OSGI webconsole, which is a gem in the “AEM performance tuning” toolbox.

In this blog post I use this tool to explain the details of the request rendering process of AEM. You can find the detailed description of this process in the pages linked from this page (Sling documentation).

Screenshot “Recent requests”

With this Recent Requests screen (goto /system/console/requests) you can drill down into the rendering process of the last 20 requests handled by this AEM instance; these are listed at the top of the screen. Be aware that if you have a lot of concurrent requests you might often miss the request you are looking for, so if you really rely on it, you should increase the number of requests which are retained. This can be done via the OSGI configuration of the Sling Main Servlet.

When you have opened a request, you will see a huge number of single log entries. Each log entry contains as first element a timestamp (in microseconds, 1000 microseconds = 1 millisecond) relative to the start of the request. With this information you can easily calculate how much time passed between 2 entries.

And each request has a typical structure, so let’s go through it using the AEM Start page (/aem/start.html). So just use a different browser window and request that page. Then check back on the “Recent requests console” and select the “start.html”.
In the following I will go through the lines, starting from the top.

      0 TIMER_START{Request Processing}
      1 COMMENT timer_end format is {<elapsed microseconds>,<timer name>} <optional message>
     13 LOG Method=GET, PathInfo=null
     17 TIMER_START{handleSecurity}
   2599 TIMER_END{2577,handleSecurity} authenticator org.apache.sling.auth.core.impl.SlingAuthenticator@5838b613 returns true

This is a standard header for each request. We can see here that the authentication took 2599 microseconds.

   2981 TIMER_START{ResourceResolution}
   4915 TIMER_END{1932,ResourceResolution} URI=/aem/start.html resolves to Resource=JcrNodeResource, type=granite/ui/components/shell/page, superType=null, path=/libs/granite/ui/content/shell/start
   4922 LOG Resource Path Info: SlingRequestPathInfo: path='granite/ui/components/shell/page', selectorString='null', extension='html', suffix='null'

Here we see the 2 log lines for a the resolving process of a resourcetype. It took 1932 microseconds to map the request “/aem/start.html” to the resourcetype “granite/core/components/login” with the path being /libs/granite/ui/content/shell/start. Additionally we see information about the selector, extension and suffix elements.

   4923 TIMER_START{ServletResolution}
   4925 TIMER_START{resolveServlet(/libs/granite/ui/content/shell/start)}
   4941 TIMER_END{14,resolveServlet(/libs/granite/ui/content/shell/start)} Using servlet BundledScriptServlet (/libs/granite/ui/components/shell/page/page.jsp)
   4945 TIMER_END{21,ServletResolution} URI=/aem/start.html handled by Servlet=BundledScriptServlet (/libs/granite/ui/components/shell/page/page.jsp)

That’s a nested servlet resolution, which takes 14 respective 21 microseconds.  Till now that’s mostly standard and hard to influence performance-wise. But it already gives you a lot information, especially regarding the resourcetype which is managing the complete response processing.

   4948 LOG Applying Requestfilters
   4952 LOG Calling filter: com.adobe.granite.resourceresolverhelper.impl.ResourceResolverHelperImpl
   4958 LOG Calling filter: org.apache.sling.security.impl.ContentDispositionFilter
   4961 LOG Calling filter: com.adobe.granite.csrf.impl.CSRFFilter
   4966 LOG Calling filter: org.apache.sling.i18n.impl.I18NFilter
   4970 LOG Calling filter: com.adobe.granite.httpcache.impl.InnerCacheFilter
   4979 LOG Calling filter: org.apache.sling.rewriter.impl.RewriterFilter
   4982 LOG Calling filter: com.adobe.cq.history.impl.HistoryRequestFilter
   7870 LOG Calling filter: com.day.cq.wcm.core.impl.WCMRequestFilter
   7908 LOG Calling filter: com.adobe.cq.wcm.core.components.internal.servlets.CoreFormHandlingServlet
   7912 LOG Calling filter: com.adobe.granite.optout.impl.OptOutFilter
   7921 LOG Calling filter: com.day.cq.wcm.foundation.forms.impl.FormsHandlingServlet
   7932 LOG Calling filter: com.day.cq.dam.core.impl.servlet.DisableLegacyServletFilter
   7935 LOG Calling filter: org.apache.sling.engine.impl.debug.RequestProgressTrackerLogFilter
   7938 LOG Calling filter: com.day.cq.wcm.mobile.core.impl.redirect.RedirectFilter
   7940 LOG Calling filter: com.day.cq.wcm.core.impl.AuthoringUIModeServiceImpl
   8185 LOG Calling filter: com.adobe.granite.rest.assets.impl.AssetContentDispositionFilter
   8201 LOG Calling filter: com.adobe.granite.requests.logging.impl.RequestLoggerImpl
   8212 LOG Calling filter: com.adobe.granite.rest.impl.servlet.ApiResourceFilter
   8302 LOG Calling filter: com.day.cq.dam.core.impl.servlet.ActivityRecordHandler
   8321 LOG Calling filter: com.day.cq.wcm.core.impl.warp.TimeWarpFilter
   8328 LOG Calling filter: com.day.cq.dam.core.impl.assetlinkshare.AdhocAssetShareAuthHandler

These are all request-level filters, which are executed just once per request.

And now the interesting part starts: the rendering of the page itself. The building blocks are called “components” (that term is probably familiar to you) and it always follows the same pattern:

  • Calling Component Filters
  • Executing the Component
  • Return from the Component Filters (in reverse order of the calling)

This pattern can be clearly seen in the output, but most often it is more complicated because many components include other components, and so you end up in a tree of components being rendered.

As an example for the straight forward case we can take the “head” component of the page:

  25849 LOG Including resource MergedResource [path=/mnt/overlay/granite/ui/content/globalhead/experiencelog, resources=[/libs/granite/ui/content/globalhead/experiencelog]] (SlingRequestPathInfo: path='/mnt/overlay/granite/ui/content/globalhead/experiencelog', selectorString='null', extension='html', suffix='null')
  25892 TIMER_START{resolveServlet(/mnt/overlay/granite/ui/content/globalhead/experiencelog)}
  25934 TIMER_END{40,resolveServlet(/mnt/overlay/granite/ui/content/globalhead/experiencelog)} Using servlet BundledScriptServlet (/libs/cq/experiencelog/components/head/head.jsp)
  25939 LOG Applying Includefilters
  25943 LOG Calling filter: com.adobe.granite.csrf.impl.CSRFFilter
  25951 LOG Calling filter: com.day.cq.personalization.impl.TargetComponentFilter
  25955 LOG Calling filter: com.day.cq.wcm.core.impl.page.PageLockFilter
  25959 LOG Calling filter: com.day.cq.wcm.core.impl.WCMComponentFilter
  26885 LOG Calling filter: com.day.cq.wcm.core.impl.monitoring.PageComponentRequestFilter
  26893 LOG Calling filter: com.adobe.granite.metrics.knownerrors.impl.ErrorLoggingComponentFilter
  26896 LOG Calling filter: com.day.cq.wcm.core.impl.WCMDebugFilter
  26899 LOG Calling filter: com.day.cq.wcm.core.impl.WCMDeveloperModeFilter
  28125 TIMER_START{BundledScriptServlet (/libs/cq/experiencelog/components/head/head.jsp)#1}
  46702 TIMER_END{18576,BundledScriptServlet (/libs/cq/experiencelog/components/head/head.jsp)#1}
  46734 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMDeveloperModeFilter, inner=18624, total=19806, outer=1182
  46742 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMDebugFilter, inner=19806, total=19810, outer=4
  46749 LOG Filter timing: filter=com.adobe.granite.metrics.knownerrors.impl.ErrorLoggingComponentFilter, inner=19810, total=19816, outer=6
  46756 LOG Filter timing: filter=com.day.cq.wcm.core.impl.monitoring.PageComponentRequestFilter, inner=19816, total=19830, outer=14
  46761 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMComponentFilter, inner=19830, total=20750, outer=920
  46767 LOG Filter timing: filter=com.day.cq.wcm.core.impl.page.PageLockFilter, inner=20750, total=20754, outer=4
  46772 LOG Filter timing: filter=com.day.cq.personalization.impl.TargetComponentFilter, inner=20754, total=20758, outer=4

At the top you see the LOG statement “Including resource …” which provides you with the information what resource is rendered, including additional information like selector, extension and suffix.

As next statement we have the resolution of the renderscript which is used to render this resource, plus the time it took (40 microseconds).

Then we have the invocation of all component filters, the execution of the render script itself, which is using a TIMER to record start time, end time and duration (18576 microseconds), and the unwinding of the component filters.

If you use a recent version of the SDK for AEM as a Cloud Service, all timestamps are in microseconds, but in AEM 6.5 and older the duration measured for the Filters (inner=…, outer=…) were printed in miliseconds (which is an inconsistency I just fixed recently).

If a component includes another component, it looks like this:

8350 LOG Applying Componentfilters
   8358 LOG Calling filter: com.day.cq.personalization.impl.TargetComponentFilter
   8361 LOG Calling filter: com.day.cq.wcm.core.impl.page.PageLockFilter
   8365 LOG Calling filter: com.day.cq.wcm.core.impl.WCMComponentFilter
   8697 LOG Calling filter: com.day.cq.wcm.core.impl.monitoring.PageComponentRequestFilter
   8703 LOG Calling filter: com.adobe.granite.metrics.knownerrors.impl.ErrorLoggingComponentFilter
   8733 LOG Calling filter: com.day.cq.wcm.core.impl.WCMDebugFilter
   8750 TIMER_START{BundledScriptServlet (/libs/granite/ui/components/shell/page/page.jsp)#0}
  25849 LOG Including resource MergedResource [path=/mnt/overlay/granite/ui/content/globalhead/experiencelog, resources=[/libs/granite/ui/content/globalhead/experiencelog]] (SlingRequestPathInfo: path='/mnt/overlay/granite/ui/content/globalhead/experiencelog', selectorString='null', extension='html', suffix='null')
  25892 TIMER_START{resolveServlet(/mnt/overlay/granite/ui/content/globalhead/experiencelog)}
  25934 TIMER_END{40,resolveServlet(/mnt/overlay/granite/ui/content/globalhead/experiencelog)} Using servlet BundledScriptServlet (/libs/cq/experiencelog/components/head/head.jsp)
  25939 LOG Applying Includefilters
[...]
148489 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMDeveloperModeFilter, inner=1698, total=1712, outer=14
 148500 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMDebugFilter, inner=1712, total=1717, outer=5
 148509 LOG Filter timing: filter=com.adobe.granite.metrics.knownerrors.impl.ErrorLoggingComponentFilter, inner=1717, total=1722, outer=5
 148519 LOG Filter timing: filter=com.day.cq.wcm.core.impl.monitoring.PageComponentRequestFilter, inner=1722, total=1735, outer=13
 148527 LOG Filter timing: filter=com.day.cq.wcm.core.impl.WCMComponentFilter, inner=1735, total=2144, outer=409
 148534 LOG Filter timing: filter=com.day.cq.wcm.core.impl.page.PageLockFilter, inner=2144, total=2150, outer=6
 148543 LOG Filter timing: filter=com.day.cq.personalization.impl.TargetComponentFilter, inner=2150, total=2154, outer=4
 148832 TIMER_END{140080,BundledScriptServlet (/libs/granite/ui/components/shell/page/page.jsp)#0}

You see the component filters, but then after the TIMER_START for the page.jsp (check the trailing timer number: #0, every timer has a unique ID!) line you see the inclusion of a new resource. For this again the render script is resolved and instead of the ComponentFilters the IncludeFilters are called, but in the majority of cases the list of filters are identical. And depending on the resource structure and the script, the rendering tree can get really deep. But eventually you can see that the the rendering of the page.jsp is completed; you can easily find it by looking for the respective timer ID.

Equipped with this knowledge you can now easily dig into the page rendering process and see which resources and resource types are part of the rendering process of a page. And if you are interested in the bottlenecks of the page rendering process you can check the TIMER_END lines which both include the rendering script plus the time in microseconds it took to render it (be aware, that this time also includes it too to render all scripts invoked from this render script).

But the really cool part is that this is extensible. Via the RequestProgressTracker you can easily write your own LOG statements, start timers etc. So if you want to debug requests to better understand the timing, you can easily use something like this:

slingRequest.getRequestProgressTracker().log("Checkpoint A");

And then you can find this log message in this screen when this component is rendered. You can use it to output useful (debugging) information or just have use its timestamp to identify performance problems. This can be superior to normal logging (to a logfile), becaus you can leave these statements in production code, and they won’t pollute the log files. You just need to have access to the OSGI webconsole, search for the request you are interested and check the rendering process.

And if you are interested, you can can also get all entries in this screen and do whatever you like. For example you can write a (request-level) filter, which calls first the next filter, and afterwards logs all entries of the RequestProgressTracker to the logfile, if the request processing took more than 1 second.

The Request Progress Tracker plus the “Recent Requests” Screen of the OSGI webconsole are a really cool combination to both help you to understand the inner working of the Sling Request Processing, and it’s also a huge help to analyze and understand the performance of request processing.

I hope that this technical deep dive into the sling page rendering process was helpful for you, and you are able to spot many interesting aspects of an AEM system just be using this tool. If you have questions, please leave me a comment below.

AEM micro-optimization (part 4) – define allowed templates

This time I want to discuss a different type of micro-optimization. It’s not something you as a developer can implement in your code, but it’s rather a question of the application design, which  has some surprising impact. I came across it when I recently investigated poor performance in the Siteadmin navigation. And although I did this investigation in AEM as a Cloud Service, the logic on AEM 6.5 behaves the same way.

When you click in the siteadmin navigation through your pages, AEM collects a lot of information about pages and folders to display them in the proper context. For example, when you click on page with child pages, it collects information what actions should be displayed if a specific child node is going to be selected (copy, paste, publish, …)

An important information is if the “Create page” action should be made available. And that’s the thing I want to outline in this article.

Screenshot: “Create” dialog

Assuming that you have the required write permissions on that folder, the most important is if templates are allowed to be created as children of the current page. The logic is described in the documentation and is quite complex.

In short:

  • On the content the template must be allowed (using the cq:allowedTemplates property (if present) AND
  • The template must be allowed to be used as a child page of the current page

Both conditions are must be met for a template to make it eligible to be used as a source for a new page. To display the entry “Page” it’s sufficient if at least 1 template is allowed.

Now let’s think about the runtime performance of this check, and that’s mostly determined by the total number of templates in the system. AEM determines all templates by this JCR query:

//jcr:content/element(*,cq:Template)

And that query returns 92 results on my local SDK instance with WKND installed. If we look a bit more closely to the results, we can determine 3 different types of templates:

  • Static templates
  • Editable templates
  • Content Fragment models

So depending on your use-case it’s easy to end up with hundreds of templates, and not all of them are applicable at the location you are currently in. In fact, typically just very few templates can be used to create a page here. That means that the check most likely needs to iterate a lot to eventually encounter a template which is a match.

Let’s come back to the evaluation if that entry should be displayed. If you have defined the cq:allowedTemplates property  on the page or it’s ancestors it’s sufficient to check the templates listed there. Typically it’s just a handful of templates, and it’s very likely that you find a “hit” early on, which immediately terminates this check with a positive result. I want to explicitly mention that not every template listed can be created here, because there also other constraints (e.g. the parent template must be of a certain type etc) which must match.

 If template A is allowed to be used below /content/wknd/en, then we just need to check the single Template A to get that hit. We don’t care, where in the list of templates it is (which are returned by the above query), because we know exactly which one(s) to look at.

If that property is not present, AEM needs to go through all templates and check the conditions for each and every one, until it finds that positive result.  And the list of templates is identical to the order in which the templates are returned from the JCR query, that means the order is not deterministic. Also it is not possible to order the result in a helpful way, because the semantic of our check (which include regular expressions) cannot be expressed as part of the JCR query.

So you are very lucky if the JCR query returns a matching template already at position 1 of the list, but that’s very unlikely. Typically you need to iterate tens of templates to get a hit.

So, what’s the impact on the performance of this iteration and the checks? In an synthetic check with 200 templates, when I did not have any match, it took around 3-5ms to iterate and check all of the results.

You might ask, “I really don’t feel a 3-5ms delay”, but when the list view in siteadmin performs this check for up to 40 pages in a single request, it’s rather a 120-200 millisecond difference. And that is a significant delay for requests where bad performance is visible immediately. Especially if there’s a simple way to mitigate this.

And for that reason I recommend you to provide “cq:allowedTemplates” properties on your content structure. In many cases it’s possible and it will speed up the siteadmin navigation performance.

And for those, who cannot change that: I currently working on changing the logic to speedup the processing for the cases where no cq:allowedTemplates property is applicable. And if you are on AEM as a Cloud Service, you’ll get this improvement automatically.
