Ways to access your content with JCR (part 1)

If you are a developer and need to work with databases, you often relay on the features your framework offers you to get your work done easily. Working directly with JDBC and SQL is not really comfortable, writing “SELECT something FROM table” with lots of constraints can be tedious …

The SQL language offers only the “select” statement to retrieve data from the database. JCR offers multiple ways to actually get access to a node:

Each of these methods serve for different purposes.

  • session.getNode(path) is used, when you know exactly the path of a node. That’s comparable to a “select * from table where path = “/content/geometrixx/en” in SQL, which is a direct lookup of a well-known node/row.
  • node.getNodes() returns all child nodes below the node. This method has no equivalent in the SQL world, because in JCR there are not only distinct and independent nodes, but nodes might have a hierarchical relation.
  • The JCR search is the equivalent of the SQL query, it can return a set of nodes. Yes, ANSI SQL 92 is much more powerful, but let’s ignore that for this article, okay?

In ANSI SQL, approach 1 and 3 are both realized by a SELECT query, while the node.getNodes() approach has no direct equivalent. Of course it can also realized by a SELECT statement (likely resolving a 1:n relation), but it highly depends on the structure of your data.

In Jackrabbit (the reference implementation of the JCR standard and also the basis for CRX) all of these methods are implemented differently.

session.getPath(): It starts at the root node and drills down the tree. So to lookup /content/geometrixx/en the algorithm starts at the root, then looks up the node with the name “content”, then looks for a child node named “geometrixx” and then for a child node named “en”. This approach is quite efficient because each bundle (you can consider it as the implementation equivalent of a JCR node) references both its parent and all the child nodes. On every lookup the ACLs on that node are enforced. So even when a node “en” exists, but the session user does not have read access on it, it is not returned, and the algorithm stops.

node.getNodes is even more efficient, because it just has to lookup the bundles of the child node list and filter it by ACLs.

If you use the JCR search, the Lucene index is used to do the search lookup and the  bundle information is used to construct the path information. The performance of this search depends on many factors, like (obviously) the amount of results returned from Lucene itself and the complexity of the other constraints.

So, as a CQ developer, you should be aware of that there are many ways to get hold of your data. And all have different performance behaviors.

In the next posting I will explain this case on a small example.

CRX 2.3: snapshot backup

About a year ago I wrote an improved version of backup for CRX 2.1 and CRX 2.2. The approach is to reduce the amount of data which is considered by the online backup mechanism. With CRX 2.3 this apprach can still be used, but now an even better way is available.

A feature of the online backup — the blocking and unblocking of the repository for write operations — is now available not only to the online backup mechanism, but can be reached via JMX.
JMX view

So, by this mechanism, you can prevent the repository from updating its disk structures. With this blocking enabled you can backup all the repository and then unblock afterwards.

This allows you to create a backup mechanism like this:

  1. Call the blockRepositoryWrites() method of the “com.adobe.granite (Repository)” Mbean
  2. Do a filesystem snapshot of the volume where the CRX repository is stored.
  3. Call “unblockRepositoryWrites()
  4. Mount the snapshot created in step 2
  5. Run your backup client on the mounted snapshot
  6. Umount and delete the snapshot

And that’s it. Using a filesystem snapshot instead of the online backup accelerates the whole process and the CQ5 application is affected (step 1 – 3) only for a very small timeframe (depending on your system, but should be done in less than a minute).

Some notes:

  • I recommend snapshots here, because they are much faster than a copy or rsync, but of course you can use these as well.
  • While the repository writes are blocked, every thread, which wants to do a write operation on the repository, will be blocked, read operations will work. But with every blocked write operation you’ll have one thread less available. So in the end you might run into a case, where no threads are available any more.
  • Currently the UnlockRepositoryWrites call can be made only by JMX and not by HTTP (to the Felix Console). That should be fixed within the next updates of CQ 5.5. Generally speaking I would recommend to use JMX directly over HTTP-calls via curl and the Felix Console.

Basic performance tuning: Caching

Many CQ installations I’ve seen start with the default configuration of CQ. This is in fact a good decision, because the default configuration can handle small and middle installations very well. And additionally you don’t have to maintain a bunch of configuration files and settings; and finally most CQ hotfixes (which are delivered without the QA) are only tested with default installations.

So when you start with your project and you have a pristine CQ installation, the performance of both publishing and authoring instances are usually very good, the UI is responsive, page load times in the 2-digit miliseconds. Great. Excellent.

When your site grows, when the content authors start their work, you need to do your first performance and stress tests using numbers provided by the requirements (“the site must be able to handle 10000 concurrent requests per second with a maximal response time of 2 seconds”). You either can overcome such requirements by throwing hardware on the problem (“we must use 6 publishers each on a 4-core machine”) or you just try to optimize your site. Okay, let’s try it with optimization first.

Caching is a thing which comes to mind first. You can cache on several layers of the application, be it application level (caches builtin into the application, like the outputcache of CQ 3 and 4), the dispatcher cache (as described here in this blog), or on the users system (using the browser cache). Each cache layer should decrease the number of requests in the remaining caches, so that in the end only the requests get through, which cannot be handled in a cache, but must be processed in CQ. Our goal is to move the files into a cache which is nearest to the enduser; then loading of these files is faster than if the load is performed from a location which is 20 000 kilometers away.

(A system engineer may also be interested in that solution, because it will offload data traffic from the internet connection. Leaves more capacity for other interesting things …)

If you start from scratch with performance tuning, grasping for the low-hanging fruits is the way to go. So you start into an iterative process, which contains of the following steps:

  1. Identify requests which can be handled by a caching layer which is placed nearer to the enduser.
  2. Identify actions, which allows to cache these requests in a cache next to the user.
  3. Perform these actions
  4. Measure the results using appropriate tools
  5. Start over from (1)

(For a more broader view to performance tuning, see David Nueschelers post on the Day developer site)

As an example I will go through this cycle on the authoring system. I start with a random look at the request.log, which may look like this:

09/Oct/2009:09:08:03 +0200 [8] -> GET /libs/wcm/content/welcome.html HTTP/1.1
09/Oct/2009:09:08:06 +0200 [8] <- 200 text/html; charset=utf-8 3016ms
09/Oct/2009:09:08:12 +0200 [9] -> GET / HTTP/1.1
09/Oct/2009:09:08:12 +0200 [9] <- 302 - 29ms
09/Oct/2009:09:08:12 +0200 [10] -> GET /index.html HTTP/1.1
09/Oct/2009:09:08:12 +0200 [10] <- 302 - 2ms
09/Oct/2009:09:08:12 +0200 [11] -> GET /libs/wcm/content/welcome.html HTTP/1.1
09/Oct/2009:09:08:13 +0200 [11] <- 200 text/html; charset=utf-8 826ms
09/Oct/2009:09:08:13 +0200 [12] -> GET /libs/wcm/welcome/resources/welcome.css HTTP/1.1
09/Oct/2009:09:08:13 +0200 [12] <- 200 text/css 4ms
09/Oct/2009:09:08:13 +0200 [13] -> GET /libs/wcm/welcome/resources/ico_siteadmin.png HTTP/1.1
09/Oct/2009:09:08:13 +0200 [14] -> GET /libs/wcm/welcome/resources/ico_misc.png HTTP/1.1
09/Oct/2009:09:08:13 +0200 [15] -> GET /libs/wcm/welcome/resources/ico_useradmin.png HTTP/1.1
09/Oct/2009:09:08:13 +0200 [15] <- 200 image/png 8ms
09/Oct/2009:09:08:13 +0200 [16] -> GET /libs/wcm/welcome/resources/ico_damadmin.png HTTP/1.1
09/Oct/2009:09:08:13 +0200 [16] <- 200 image/png 5ms
09/Oct/2009:09:08:13 +0200 [13] <- 200 image/png 17ms
09/Oct/2009:09:08:13 +0200 [14] <- 200 image/png 17ms
09/Oct/2009:09:08:13 +0200 [17] -> GET /libs/wcm/welcome/resources/welcome_bground.gif HTTP/1.1
09/Oct/2009:09:08:13 +0200 [17] <- 200 image/gif 3ms

Ok, it looks like that some of such requests must not be handled by CQ: the PNG files and the CSS files. These files usually never change (or at least change very seldom, maybe on a deployment or when a hotfix is deployed). But for the usual daily work of an content author they can be assumed to be static, but we must of course provide a way that we enable the authors to fetch a new one, when an update to one them occurs. Ok, that was step 1: We want to cache the PNG and the CSS files which are placed below /libs.

Step 2: How can we cache these files? We don’t want to cache them within CQ (that wouldn’t bring any improvement), so remains dispatcher and browser cache. In this case I recommend to cache them in the browser cache for 2 reasons:

  • These files are requested more than once during a typical authoring session, so it makes sense to cache directly in the browser cache.
  • Latency of the browser cache is ways lower than the latency of any load from the network.

As an additional restriction which speaks against the dispatcher:

  • There are no flusing agents for authoring mode, so we cannot use the dispatcher that easily. So in the case of tuning an authoring instance we cannot use the dispatcher cache.

And to make any changes to these files made on the server visible to the user, we can use the expiration feature of HTTP. This allows us to specify a time-to-live, which basically tells any interested party, how long we consider this file up-to-date. When this time is reached, every party, which cached it, should remove it from cache and refetch.
This isn’t the perfect solution, because a browser will drop the file from its cache and refetch it from time to time, although the file is still valid and up-to-date.
But there’s still an improvement, if the browser fetches this files every hour instead of twice a minute (when a page load occurs).

Our prognose is, that the browser of an authoring user won’t perform that much requests on files anymore; this will increase the rendering performance of the page (the files are fetched from the fast browsercache instead from the server), and additionally the load on the CQ will decrease, because it doesn’t need to handle that much requests. Good for all parties.

Step 3: We implement this feature in the apache webserver, which we have placed in front of our CQ authoring system and add the following statements:

<LocationMatch /libs>
ExpiresByType image/png "access plus 1 hour"
ExpiresByType text/css "access plus 1 hour"
</LocationMatch>

Instead of relying on file extensions we specify here the expiration by the MIME-type in these rules. The files are considered to be up-to-date for an hour, so the browser will reload these files every hour. This value should be ok also in case these files are changed once. And if everything fails, the authoring users can drop their browser cache.

Step 4: We measure the effect of our changes using 2 different strategies: First we observe the request.log again and check if these requests appear further on. If the server is already heavy loaded, we can additionally check for a decreasing load and an improved response times for the remaining requests. As a second option we take a simple use case of an authoring user and run it with Firefox’ Firebug extension enabled. This plugin can visualize how and when the load of the parts of a page happen, and display the response times quite exactly. You should see now, that the number of files requested over the network has decreased and the load of a page and all its emnbedded objects is faster than before.

So with an quick and easy-to-perform action you have decreased the page load times. When I added expiration headers to a number of static images, javascripts and css files on a publishing instance, the number of requests which went over the wire went down to 50%, the pageload times also decreased, so that even during a stress test the site still had a good performance. Of course, dynamic parts must be handled by their respective systems, but if we can offload requests from CQ, we should do this.

So as a conclusion: Some very basic changes to the system (some configuration adjustments to the apache config) may increase the speed of your site (publishing and authoring) dramatically. Such changes as described are not invasive to the system and are highly adjustible to the specific needs and requirements of your application.

Permission sensitive caching

In the last versions of the dispatcher (starting with the 4.0.1 release) Day added a very interesting feature to the dispatcher, which allows one to cache also content on dispatcher level which are not public.
Honwai Wong of the Day support team explained it very well on the TechSummit 2008. I was a bit suprised, but I even found it on slideshare (the first half of the presentation)
Honwai explains the benefits quite well. From my experience you can reduce the load on your CQ publishers (trading a request which requires the rendering of a whole page to to a request, which just checks the ACLs of a page).

If you want to use this feature, you have to make sure that for every group or user, who has to have a individual page, the dispatcher delivers the right one. Imagine you want the present the the logged-in users the latest company news, but not logged-in users shouldn’t get them. And only the managers get the link to the the latest financial data on the startpage. So you need a startpage for 3 different groups (not-logged-in users, logged-in users, managers), and the system should deliver it appropriatly. So having a single home.html isn’t enough, you need to distinguish.

The easiest way (and the Day-way ;-)) is to use a selector denoting the group the user belongs to. So home.group-logged_in.html or home.managers.html would be good. If no selector is given, we assume the user to be an anonymous user. You have to configure the linkchecker to rewrite all links to contain the correct selector. So if a user belongs to the logged_in group and requests the home.logged_in.html page, the dispatcher will ask the CQ ” the user has the following http header lines and is requesting the home.logged_in.html, is it ok?”. CQ then checks if the given http header lines do belong to a user of the group logged_in; because he is, it responses with “200 OK, just go on”. And then the dispatcher will deliver the cached file and there’s no need for the CQ to render the same page again and again. If the users doesn’t belong to that group, CQ will detect that and send a “403 Permission denied”, and the dispatcher forwards this answer then to the user. If a user is member of more than one group, having multiple “group-“selectors is perfectly valid.

Please note: I speak of groups, not of (individual) users. I don’t think that this feature is useful when each user requires a personalized page. The cache-hit ratio is pretty low (especially if you include often-changing content on it, e.g daily news or the content of an RSS feed) and the disk consumption would be huge. If a single page is 20k and you have a version cached for 1000 users, you have a disk usage of 20 MB for a single page! And don’t forget the performance impact of a directory filled up with thousands of files. If you want to personalize pages for users, caching is inappropriate. Of course the usual nasty hacks are applicable, like requesting the user-specific data via an AJAX-call and then modifying the page in the browser using Javascript.

Another note: Currently no documentation is available on the permission sensitive caching. Only the above linked presentation of Honwai Wong.

Creating cachable content using selectors

The major difference between between static object and dynamically created object is that the static ones can be stored in caches; their content they contain does not depend on user or login data, date or other parameters. They look the same on every request. So caching them is a good idea to move the load off the origin system and to accelerate the request-response cycle.

A dynamically created object is influenced by certain parameters (usually username/login, permissions, date/time, but there are countless other) and therefor their content may be different from request to request. These parameters are usually specified as query parameters and must not be cached (see the HTTP 1.1 specification in RFC 2616).

But sometimes it would be great, if we could combine these 2 approaches. For example you want to offer images in 3 resolutions: small (as a preview image e.g in folder view), big (full screen view) and original (the full resolution delivered by the picture-taking device). If you decide to deliver it as static object, it’s cachable. But you need then 3 names (one for each resolution), one for each resolution. Choosing this will blur the fact that these 3 images are the same and differ only in the fact of the image resolution. It creates 3 images instead having only one in 3 instances. Amore practical drawback is that you always have to precompute these 3 pictures and place them on a reachable location. Lazy generation is hard also.

If you choose the dynamic approach, the image would be available as one object for which the instance can be created dynamically. The drawback is here that it cannot be cached.

Day Communique has the feature (the guys of Day ported it also to Apache Sling) to use so-called selectors. They behave like the query parameters one used since the stoneage of the HTTP/HTML era. But they are not query parameters, but merely encoded in the static part of the URL. So the query part of the ULR (as of HTTP 1.1) is no longer needed.

So you can use the URLs /etc/medialib/trafficjam.preview.jpg, /etc/medialib/trafficjam.big.jpg and /etc/medialib/trafficjam.original.jpg to adress the image in the 3 required resolutions. If your dispatcher doesn’t find them in its cache, it will forward the request to your CQ, which can then scale the requested image on demand. Then the dispatcher can store the image and deliver it then from its cache. That’s a very simple and efficient way to make dynamic objects static and offload requests from your application servers.

Joergs rules for loadtests

In the article “Everything is content (part 2)” I discussed the problems of doing proper loadtests with CQ with respect to your CQ which gets (a bit) lower by every loadtest. In a comment Jan Kuźniak proposed to disable versioning and to restore your loadtest environment for every loadtest. Thinking about Jans contribution revealed a number of topics I consider as crucial for loadtests. I collected some of them and would like to share them.

  • Provide a reasonable amount of data in the system. This amount should be kind of equal to your production system, so the numbers are comparable. Being 20% off doesn’t matter, but don’t expect good results if your loadtest runs on 1000 handles but your production system heads directly to 50k handles. You may optimize the wrong parts of your code then.
    When you benchmarked a speedup of 20% in the loadtests but got nothing in production system, you already saw it.
  • When your loadtest environment is ready to run, create a backup of it. Drop the CQ loadtest installation(s) from time to time, restore it from the backup and re-run your loadtest a clean installation to verify your results. The point I already mentioned.
  • Always have the same configuration in the production and loadtest environment. That’s the reason why I disagree to disable versioning on the loadtesting environment. The effect of diverging configuration may be the same as in the above point: You may optimize the wrong parts of your code.
  • No error messages during loadtest. If an error messages indicates a code problem, it’s probably reproducable by re-running the loadtest (come on, reproducable bugs are the easiest ones to fix :-)). If it’s a content problem you should adjust your content. A loadtest is also a very basic regression test, so take the results (errors belong there also!) seriously.
  • Be aware of ressource virtualization! Today’s hype is to run as much applications as possible on virtualized environments (VMWare, KVM, Solaris zones, LPARs, …) to increase the efficency of the hardware usage and lower costs. Doing so very often removes some guarantees you need for comparing results of different loadtests. For exmple on one loadtest you have 4 CPUs for you, while on the second one you have 6 CPUs available. Are the results comparable? Maybe they are, maybe not.
    Being limited to always 4 CPUs offers comparable loadtests, but if your production systems requires 8 CPUs, you cannot load your loadtest system with production level numbers. Getting a decent loadtest environment is a hard job …
  • Have good test scenarios. Of course the most basic requirement. Don’t just grab the access.log and throw it at your load injector. Re-running GET requests is easy, but forget about POSTs. Modelling good scenarios is hard and needs much time.

Of course there are a lot of more things to consider, but I will limit myself to these points at the moment. Eventually there will be a part 2.

META: Being linked from Day

Today this blog was presented as link of the day on dev.day.com. Thanks for the kudos 🙂

Welcome to all who read this blog for the first time. I’ve collected some experiences with Day CQ here and will share my experience and others thoughts furtheron. Don’t hesitate to comment or drop me an email if you have a question to an post.

Please note: I am not a developer, so I cannot help you with specific question to template programming. In that case you can contact one of the groups mentioned on the Day Developer website.

Visualize your requests

In the last year, customers often complained about our bad performance. We had just fixed a small memory leak (which crashed our publishing instances about every hour or so), so we were quite interested in getting reliable data to confirm or deny their anger. That time I thought that we need to have a possibility to get a quick overview of the performance of our CQ instances. One look to see “Ok, it must be the network, our systems perform great!”

So I dug out my perl knowhow and wrote a little script which parses through a request.log and prints out data which which is understood by gnuplot. And gnuplot draws then some nice graphs of it. It displays the number of requests per minute and also the average request duration for these requests.

request-graph-all(Click on the image for a larger version.)

These images proved themselves as pretty useful, because you show them to your manager (“Look, the average response went down from 800 miliseconds to 600 although the number of requests went up by 30%.”) and they help you in daily bussiness, because you can spot problems quite well. When at a certain time the response times go up, you better had a look at the system and find the reason for it.

request-graph-html-ukBecause this scripts is quite fast (it parses 300 megabytes of request.log in about 15 seconds on a fast Opteron-based machine), we usually render these images online and integrate the resulting images in a small web application (no CQ but a small hacked up PHP script). For some more interactivity I added the possibility to display only the requests which matches a certain string  (click on the image to view a larger version). So it’s very easy to answer questions such “Is the performance of my landing page that bad as customer report?”

You can download this little perl script here. Run it with “–help” first and it will display a little help screen. Give a number of request.log files as parameter to it, pipe the output directly into gnuplot (I tested with version 4.0, but will probably also work with newer versions) and it will output a png file. Adjust the scripts to your needs and contribute back, I released it under GPL version 2.

(For the hackers: Some things can probably be performed better and I also have some new functionality already prepared in it, but not active. Patches are welcome :-))

Everything is content (part 2)

Recently I pointed out some differences in the handling of the “everything is content” paradigma of Communique. A few days ago I found a posting of David Nüscheler over at dev.day.com, in which he explained the details of performance tuning.

(His 5 rules do not apply exclusively to Day Communique, but to every performance tuning session).

In Rule 2 he states:

Try to implement an agile validation process in the optimization phase rather than a heavy-weight full blow testing after each iteration. This largely means that the developer implementing the optimization has a quick way to tell if the optimization actually helped reach the goal.

In my experience this isn’t viable in many cases. Of course the developer can check quickly, if his new algorithm performs better ( = is faster) than the older one. But in many cases the developer doesn’t have all the ressources  and infrastructure available and doesn’t have all the content in his test system; which is the central point why I do not trust tests performed on developer systems. So the project team relies on central environments which are built for load testing, which have loadbalancers, access to directories, production-ready sized machines and content which is comparable to the production system. Once the code is deployed, you can do loadtesting. Either using commercial software or just using something like jmeter. If you can use Continious integration and and a autodeployment system, you can do such tests every day.

Ok, where have I started? Right, “everything is content”. So you run your loadtest. You create handles, modify them, activiate and drop them, you just request a page to view, you perform acitivies in your site, and so on. Afterwards you look at your results and hopefully they are better than before. Ok. But …

But Communique is not built to forget data — of course it does sometimes, but that’s not the point here :-), so all these activities are stored. Just take a look at the default.map, the zombie.map, the cmgr.hist file, … So all your recent actions are persisted and CQ knows of them.

Of course handling more of such information doesn’t make CQ faster. In case you have long periods of time between your template updates: Check the performance data directly after a template update and compare them to the ones a few months after (assuming you don’t have CQ instances which aren’t used at all). You will see a  decrease in performance, it can be small and nearly unmeasurable, but it is there. Some actions are slower.

Ok, back to our loadtest. If you run the loadtest again and again and again, a lot of actions are persisted. When you reproduce the code and the settings of the very first loadtest and run the very first loadtest again, and you do that on a system which already faced 100 loadtests, you will see a difference. The result of this 101st loadtest is different from the first one,although the code, the settings and the loadtest are essentially the same. All the same except CQ and its memory (default.map and friends).

So, you need a mechanism which allows you to undo all changes made by such a loadtest. Only then you can perfectly reproduce every loadtest and run them 10 times without any difference in the results. I’ll try to cover such methods (there are some of them, but not all equally suitable) in some of the next posts.

And to get back to the title: Everything is content, even the history. So in contrary to my older posting,where I said:

Older versions of a handle are not content.

They are indeed content, but only when it comes to slowing down the system 🙂
